Custom Crane Maintenance Platform: A Safe and Efficient Access Solution for Industrial Maintenance

Industrial crane maintenance requires reliable access equipment that prioritizes safety, stability, and operational efficiency. At Al Jarsh Metal Sections Manufacturing LLC, we specialize in designing and manufacturing custom aluminium access solutions tailored to the unique requirements of industrial facilities across the Middle East.

This project demonstrates how our engineering expertise transformed a customer's maintenance challenge into a practical, durable, and safe access platform designed for long-term industrial use.

Understanding the Client's Requirements

The project began with an inquiry from a client seeking a custom crane maintenance platform for routine maintenance operations. As every industrial facility presents unique challenges, our engineering team first reviewed photographs of the maintenance area to gain a clear understanding of the working environment and identify any potential design constraints.

To ensure complete design accuracy, we requested the client to complete our standard engineering assessment documents:

• Dimension Verification Sheet (DVS) – to provide accurate site measurements.

• Work Environment Assessment (WEA) – to evaluate operating conditions, environmental factors, and safety requirements.

Gathering this information during the initial stage enabled us to develop an access solution that met both opertional and safety requirements while minimizing the need for site modifications.

Engineering a Tailored Access Solution
The client’s associated partner, illustrated their desired maintenance arrangement. Our design engineers carefully analysed the requirements,  maintenance procedures, and available workspace before developing a fully customized crane maintenance platform.

The final design incorporated several key customer requirements:

• 1. Heavy-Duty Wheels for Uneven Surfaces

  One of the primary design considerations was the site's uneven asphalt surface. To ensure smooth mobility without compromising stability, the client requested tyre-tread wheels.

  After evaluating the application, we incorporated heavy-duty rubber tyres that provide:

  • Improved mobility across uneven industrial surfaces.

  • Enhanced platform stability during maintenance operations.

  • Reduced vibration during transportation.

  • Greater operator safety and easier maneuverability.

• Forklift Handling Provision

  To improve mobility throughout the maintenance yard, forklift lifting points were incorporated into both sections of the platform. This allows the equipment to be transported safely and efficiently whenever required.

• Railing Storage Holders

  Dedicated holders were integrated into the platform to store removable guardrails whenever unrestricted access was required on one side during maintenance activities. This feature improves convenience while maintaining workplace safety.

• Steel Grating Platform and Steps

  Steel grating was specified for all working platforms and steps to provide:

  • Excellent slip resistance.

  • Long service life.

  • Effective drainage of liquids and chemicals.

  • Safe operation in demanding industrial environments.


Every component was carefully selected to maximize durability, functionality, and long-term performance.

Our Engineering Solution

Following several technical discussions and design reviews with the client, we developed a customized solution that addressed every operational requirement.

Our solution included:

• Comprehensive review of all client parameters

• Engineering recommendations based on the client's maintenance application.

• A modular, dismantlable platform for easier transportation, installation, and storage.

• Secure locking mechanisms between major structural components, as structure needed to be stored in compact spaces, and therefore our solution was made of 2 adjoining parts.

• Heavy-duty tyre-tread wheels suitable for rough outdoor industrial surfaces.

• Multiple removable railing storage provisions.

• Forklift lifting points integrated into both sections of the platform, to easily transport the ladder efficiently.

• Steel grating on all platforms and steps, supported by reinforced structural framing, to tackle issue of grease during maintenance, and prevent operational hazard.

• A dedicated counterweight tray to maintain structural stability during operation.

• Full compliance with the client's safety and operational specifications.

Throughout the project, our engineering team worked closely with the client to ensure every design detail aligned with their maintenance procedures, operational requirements, and workplace safety standards.
